SAP B1 Service Layer API: A Developer's Complete Reference

Overview: What Is the Service Layer?

The SAP Business One Service Layer is a RESTful API server that ships with SAP B1 version 9.0 and later. It exposes SAP B1 business objects as HTTP resources, allowing any application — regardless of technology stack — to create, read, update, and delete records in SAP B1 over standard HTTPS.

Before the Service Layer, the only way to integrate with SAP B1 programmatically was via the COM-based DI API, which required a Windows client installation on the calling machine. The Service Layer removed this constraint, enabling cloud-hosted middleware and web applications to communicate with SAP B1 securely over the internet.

Base URL Structure

All Service Layer requests are made to a base URL in the following format:

https://[your-sap-b1-server]:[port]/b1s/v1/

Replace [your-sap-b1-server] with your server's hostname or IP address, and [port] with the configured Service Layer port. All endpoints branch off this base URL.

Authentication & Session Management

The Service Layer uses session-based authentication. You must POST a login request before calling any other endpoint. A successful login returns a session cookie that must be included in all subsequent requests.

Login Request

POST /b1s/v1/Login
Content-Type: application/json

{
  "CompanyDB": "YOUR_COMPANY_DB_NAME",
  "UserName":  "manager",
  "Password":  "your_password"
}

On success, the response contains a Set-Cookie header with a B1SESSION value. Store this cookie and send it with every subsequent request.

Session Handling Best Practices

• Sessions expire after the configured idle timeout (typically 30 minutes). Your middleware must detect 401 Unauthorized responses and re-authenticate automatically.
• Do not create a new session per request — session creation has overhead. Reuse sessions and renew only when they expire.
• Always call POST /b1s/v1/Logout when your application is shutting down to free server-side session resources.

Querying Data (GET)

The Service Layer supports standard OData query options for filtering, sorting, and paginating results.

Get a Collection

GET /b1s/v1/BusinessPartners
Cookie: B1SESSION=your_session_token

OData Filter Examples

-- Filter by field value
GET /b1s/v1/Orders?$filter=CardCode eq 'C001'

-- Select specific fields only
GET /b1s/v1/Items?$select=ItemCode,ItemName,OnHand

-- Combine filter, select and order
GET /b1s/v1/Invoices?$filter=DocStatus eq 'O'&$select=DocEntry,CardName,DocTotal&$orderby=DocDate desc

-- Pagination (skip 20, take 10)
GET /b1s/v1/Orders?$skip=20&$top=10

Creating & Updating Records (POST / PATCH)

Create a Sales Order

POST /b1s/v1/Orders
Content-Type: application/json
Cookie: B1SESSION=your_session_token

{
  "CardCode": "C001",
  "DocDate":  "2025-08-01",
  "DocumentLines": [
    {
      "ItemCode":   "ITEM-001",
      "Quantity":   5,
      "UnitPrice":  100.00
    }
  ]
}

Partial Update with PATCH

PATCH /b1s/v1/Orders(12345)
Content-Type: application/json
Cookie: B1SESSION=your_session_token

{
  "Comments": "Updated via integration"
}

Error Handling

The Service Layer returns standard HTTP status codes. Here are the most important ones to handle in your middleware:

• 200 OK — Successful GET or PATCH
• 201 Created — Successful POST (record created)
• 400 Bad Request — Validation failure. Check the response body for SAP's error message and code.
• 401 Unauthorized — Session expired. Re-authenticate and retry.
• 404 Not Found — The requested entity key does not exist.
• 500 Internal Server Error — A SAP B1 business rule or database error occurred. Log the response body for debugging.

Key Endpoint Reference

The following endpoints cover the most common integration scenarios:

• Business Partners: /b1s/v1/BusinessPartners
• Sales Orders: /b1s/v1/Orders
• AR Invoices: /b1s/v1/Invoices
• Items / Products: /b1s/v1/Items
• Item Warehouses (Stock): /b1s/v1/Items('[ItemCode]')/ItemWarehouseInfoCollection
• Incoming Payments: /b1s/v1/IncomingPayments
• Deliveries: /b1s/v1/DeliveryNotes
• Purchase Orders: /b1s/v1/PurchaseOrders
